SPDIF (optical)

Audio Output (3.5mm)

Audio Input (3.5mm)

USB (service)

1

Audio Input (RCA)

USB

1

12V Trigger

Composite Video Input (RCA)

RS232 (DB-9pin)

VGA Input

1

MHL

Ethernet (RJ45)

Speaker Power, W

10

Integrated Speakers

Sound Type

mono

Zoom Ratio

1.6x

Lens Shift

vertical +/- 15%

Focal Length, Mm

18.2 - 29.2

F-number

1.51 - 1.99

Projection Distance, M/ft

1.6 - 7.2/3.2 - 22.9

Noise Level, DBA

37

Projection Screen Size, Inch

60 - 150

Projection System

3LCD

Pixel Number

2073600

Color Reproduction

1.07 billion

Throw Ratio Range

1.33 - 2.16

Contrast Ratio

60000:1

Brightness, Lumens

2500

Power Consumption, W

312

Aspect Ratio

16:9

Input Lag, Ms

28

Lamp Type, W

200

Lamp Life (eco Mode), Hours

7500

Lamp Life (normal Mode), Hours

4500

Projection Method

front, rear, ceiling mount, tabletop

Security

password protection

3D

Mouse Functions

REMOTE CONTROL

Weight, Kg/pounds

3.49/7.7

Size W X H X D, сm/inches

30.99 x 28.45 x 12.19/12.2 x 11.2 x 4.8

Resolution Abbreviation

Full HD

Max Resolution (resized)

1920 x 1080

Native Resolution

1920 x 1080

SECAM

PAL

NTSC

Max, C/F

35/95

Min, C/F

5/41

Keystone Adjustment Horizontal, +- Degrees

30

Keystone Adjustment Vertical, +- Degrees

30
